Caterpillar Earth Moving TV6135 Turbo 465984-0005

Caterpillar Earth Moving TV6135 Turbo 465984-0005
Item# turbo-earth-moving-cat-TC-4659840005
$1,856.25
Availability: Usually ships the next business day

Product Description


Part Number 465984-0005
Previous Part Number 465984-0003
OE number 1W8178
Description Earth Moving
CHRA409043-0050 (409043-S050S, 409043-0006)(1W6865, 0R5869, 6N6612) $989.92 NEW IN STOCK, MADE IN USA
Turbo ModelTV6135, TV6135C
Engine3306, 3306 PCTAJWAC 101ININDUSTR
FuelDiesel
Bearing Housing408495-0028 (9N2035)(Oil Cooled) $152.10 NEW IN STOCK
Turbine Wheel408493-0007 (6N6611)(408493-0016)(Ind. 77.76 mm, Exd. 55.3 mm, Trm 13.5, 11 Blades) $414.10 NEW IN STOCK
Comp. Wheel409318-0008 (408495-0028, 408455-0033)(9N2035)(Ind. 59.72 mm, Exd. 86.4 mm, 8+8 Blades, Superback $265.12 NEW IN STOCK
Back plate408487-0016 (6N8630)(409368-0001, 408487-0003) NEW IN STOCK
Heat shield Number407778-0001 (9S9327) $101.72 NEW IN STOCK
Repair Kit468103-0000 (3545836)(Major) $97.20 NEW IN STOCK
Turbine Housing408142-0026 (6N6614)
Compressor Cover409603-0002 (407009-0147)(1W6866) $195.00
Turbine Housing AR 1,34
Gasket (turbine inlet)409038-0001 (210835-0000, 9749, 7M7273, 210017-0000, 132040, 3500683, 205396, 202873, 1S4295, 409038-0000)(1900000003) $14.02
Gasket oil inlet210019 (129119) $4.40
Gasket (oil outlet)210018 (129120) $4.22
Gasket Kit215082
Manufacturer Honeywell-Garrett

Applications

Caterpillar Earth Moving with 3306 Engine

Core Charge

There is a $500.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
