Part Number | 466272-5005S |
Previous Version | 466272-0005, 466272-0001, 466272-0002, 466272-0003, 466272-0004, 466272-9005, 466272-5, 466272-1, 466272-2, 466272-3, 466272-4 |
OE Number | 8944073590, 8944073591, 2910096000, 8941282540 |
Year | 1984-91 |
Description | Industrial, Truck Trooper, Pickup |
CHRA | 430425-0053 (430425-5053S, 430425-0025, 430425-0010) $350.00 NEW IN STOCK, MADE IN USA |
Turbo Model | TB0209 |
Engine Model | C223T, UBS52, 4WD |
Fuel | Diesel |
KW | 77/80 |
Displacement | 2.2L, 2200 ccm, 4 Cylinders |
SN | PF0401 |
Angle α (compressor housing) | 70/302° |
Angle β (turbine housing) | 125/262° |
Bearing Housing | 430936-0008/432257-0009 $68.40 NEW IN STOCK |
Turbine Wheel | 435243-0002 (435243-0001, 435243-0004, 435243-0005, 435259-0001, 435737-0001, 435737-0006, 443850-0001) (Ind. 47. mm, Exd. 35.25 mm, Trm 56, 11 Blades) (1100020435) $89.80 NEW IN STOCK |
Comp. Wheel | 410450-0014/410450-0001 (Ind. 48. mm, Exd. 37.18 mm, Trm 60, 8 Blades) $55.00 NEW IN STOCK |
Back plate | 432280-0001/430612-0003 (1100025300) $14.00 NEW IN STOCK |
Heat shield Number | 430871-0002/431055-0003 $13.84 NEW IN STOCK |
Repair Kit | 709342-0001 (445118-0001, 430875-0001 )(1100025763) $75.00 NEW IN STOCK |
Turbine Housing | 430609-0029 IN STOCK |
Compressor Cover | 409589-0051 IN STOCK |
Turbine Housing AR | 0.63 |
Actuator | 430819-0018 NEW IN STOCK |
Settings waste gate (pressure) | 0.780-0.850/0.880-1.000 bar |
Settings Waste gate (lift shaft) | 1.00/4.00 mm |
Gasket (turbine inlet) | 210218 (Stainless Steel) $16.00 |
Gasket (turbine outlet) | 210217 (Stainless Steel) |
Manufacturer | Honeywell-Garrett |
1984-91 Isuzu Trooper, Pickup with C223T, UBS52 Engine There is a $100.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received. This part comes with ONE YEAR unlimited mileage warranty.Applications
Core Charge
Warranty
