Home > Force Inductions > TURBO CHARGERS > VARIOUS > CUMMINS > 1989- Cummins Various HC5A Turbo 3594068

1989- Cummins Various HC5A Turbo 3594068

Item# turbo-various-cummins-TC-3594068
$2,977.00
Availability: Usually ships the next business day

Product Description


Part Number 3594068
Previous versions3524733, 3524734, 3594069, 466000-0001
OE number3801562, 3801562NX, 3801562RX, 3801727, 3801727NX, 3801727RX
Description Various
Manufacturer Part Number 3594069
CHRA3594213 (3545513) $980.28 NEW IN STOCK
Turbo Model HC5A, HC5A-3091M/N69M4
Manufacturer Part Number3524734, 3594069
Engine KT
Engine Manufacturer Cummins
FuelDiesel
Angle α (compressor housing) 346.5/360°
Angle β (turbine housing) 90/360°
Bearing Housing 3595036 (3523429)(359503600)(Oil Cooled)(1900011448) $445.02 NEW IN STOCK
Turbine Wheel3521034 (352103400)(Ind. 1111.6 mm, Exd. 129. mm, Trm 19, 11 Blades)(1152105436) $598.00 NEW IN STOCK
Comp. Wheel3523546 (Ind. 103.8 mm, Exd. 131. mm, 8+8 Blades)(1152105403) $435.94 NEW IN STOCK
Back plate3524421 (352442100) $203.05 NEW IN STOCK
Heat shield Number3536588 (3519783, 353658800)(1153080340) $48.74 NEW IN STOCK
Repair Kit3545647 (3575236)(1152105750, 5000020020) $127.40 NEW IN STOCK
Gasket (turbine Inlet) 409265-0000 (Inox Steel) $18.04
Gasket (oil outlet)210018 (210018-0000, 129120, 409267-0002, 201048, 157602, 3037537, 3709738, 3500682, 201048, 1S4810, 9988, 9738, 3519763) (1900000025) $4.38 $8.22
ManufacturerHOLSET

Applications

21989- Cummins Various with KT Engine

Core Charge

There is a $500.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
