1991-98 Alfa Romeo 164 2.5L TD TD05 Turbo 49178-07200

1991-98 Alfa Romeo 164 2.5L TD TD05 Turbo 49178-07200
Item# turbo-car-alfa-TC-4917807200
$1,479.00
Availability: Usually ships the next business day

Product Description


Part Number 49178-07200
Previous Version4917807200
OE number60513721, 46234259
DescriptionAlfa-Romeo 164
CHRA49178-07300 (4917807300)(1000-050-115) $350.00 NEW IN STOCK, MADE IN USA
Turbo ModelTD05H-12B-6
EngineM631AT20C
Engine Manufacturer Alfa Romeo
Displacement2.0L, 1996 ccm, V6 Cylinders
KW201/204 HP
Fuel Gas
Bearing Housing49178-26300 (49178-25300)(Water Cooled)(1900011003D) $122.88 NEW IN STOCK
Turbine Wheel49178-30230 (Ind. 97. mm, Exd. 55.98 mm, Trm 17.14, 12 Blades)(1100016002) $104.67 NEW IN STOCK
Comp. Wheel49178-40410 (Ind. 41.25 mm, Exd. 57.98 mm, Trm 5.51, 6+6 Blades, Superback)(1200016155) $49.87 NEW IN STOCK
Back plate49168-22500 (1800016014) $28.92 NEW IN STOCK
Heat shield Number 49168-22200 (49168-18900, 193975)(2030016029) $13.48 NEW IN STOCK
Repair Kit49178-81100 (5000050015) NEW IN STOCK
Turbine Housing49178-16200 (49178-16201)
Compressor Cover49178-56930
Turbine Housing AR6.0
Actuator49178-17900 (2061016507)
Replaced by49178-02300
Gasket (turbine inlet) 210360 (Stainless Steel) $24.00
Gasket (oil outlet)210243 (Paper) $2.57
ManufacturerMitsubishi

Applications

1991-98 Alfa-Romeo 164 2.0 T Engine AR64102, AR64101 6 Cyl.

Core Charge

There is a $100.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
